Omnitronic PAP-350

Reliable amplifierThe Omnitronic PAP-60 ELA mixer amplifier is your reliable partner for ELA sound reinforcement systems. Thanks to its 19'' format, it is ideal for both mobile and fixed installations. Outputs for ELA loudspeakers with 70 V and 100 V audio carriers or 4-16- ? loudspeakers leave nothing to be desired. In addition to a line input, the PAP-60 also offers a loop-through output. Choose between XLR and 6.3 mm jack for both. So you`re always flexible. Protection A fan protects the interior of your PAP-60 from overheating. In addition to a switch-on delay, it also features protection circuits against overload, short-circuit and DC voltage. In these cases, your loudspeakers are electrically isolated from the amplifier. Both the PAP-60 and your speakers are protected from damage. PA power amplifier, 60 watts1 line input (optionally XLR or 6.3 mm jack) 1 feed-through output (optionally XLR or 6.3 mm jack) 70 V, 100 V or 4-16 ohms operation Master control LED indicators for power, signal, clip and fault Protective circuits: over load, short circuit, turn-on delay, over heating, DC offset protection Load detection and power control Rack installation Housing design: (19'') 48.3 cm rack installation 2 U

Technické parametry:

Power supply
230 V AC, 50 Hz

Frequency range
60 - 16000 Hz

Power connection
Fixed Power supply cord with safety plug

Impedance
100 V ELA

Output power
60 W RMS

Housing design
(19'') 48.3 cm rack installation 2 U

Width
48,3 cm

Height
8,9 cm

Depth
38,5 cm

Weight
7,90 kg

Output power
60 W RMS

Output current
0.85 A/ 70 V, 0.6 A/ 100 V

Speaker outputs
70 V, 100 V or 4-16 ohms

Input connectors
XLR, 6.3 mm jack mounting socket

Output connectors
XLR, 6.3 mm jack mounting socket

Line input
800 mV, 10 kohms

Distortion
0.5 %/ 1 kHz

S/N ratio (line)
90 dB

Protection
Overheat, overload, short-circuit, DC, softstart

Indicators
Power, fault, clip, signal

Dimensions
483 x 335 x 92 mm

Rack installation with 2 U

Hmotnost balení:
9.6 kg

Velikost balení:
54 x 47 x 18.5 cm
