Main Specifications Device Type Ethernet Controller Dimensions (WxDxH) Card PCB dimensions: 5.9in (14.99cm) x 2.73in (6.90cm) (L x H) Height of end brackets: standard - 4.725in (12cm), low-profile - 3.13in (7.94cm) Form Factor Low-Profile Standard Short-length Form Factor Interface (Bus) Type PCI Express 3.0 (8GT/s) Networking Controller Type Intel® XL710-BM1 Data Transfer Rate 10GbE Port Quantity Quad RJ45 connectors with speed up to 10Gb/s per port Virtualization Features Next-Generation... Celý popis
Koupit za 18 307 Kč- Od nejoblíbenějších
- Od nejlevnějších
- Od nejdražších
96 %
SUPERMICRO Standard LP 4-port 10GbaseT, Intel XL710 and X557 - Supermicro AOC-STG-I4T-O
Doprava:
zdarma
Skladem
18 307 Kč
Koupit za 18 307 Kč
92 %
Supermicro Add-on Card AOC-STG-I4T (AOC-STG-I4T-O)
Doprava:
zdarma
Skladem
18 296 Kč
Koupit za 18 296 Kč
96 %
SUPERMICRO AOC-STG-I4T Quad 10Gb/s RJ45, PCI-E 3.0 8x (8GT/s) Card, LP
Doprava:
89 Kč
Skladem
17 726 Kč
Koupit za 17 726 Kč
Popis
Main Specifications
Device Type Ethernet Controller
Dimensions (WxDxH) Card PCB dimensions: 5.9in (14.99cm) x 2.73in (6.90cm) (L x H)
Height of end brackets: standard - 4.725in (12cm), low-profile - 3.13in (7.94cm)
Form Factor Low-Profile Standard Short-length Form Factor
Interface (Bus) Type PCI Express 3.0 (8GT/s)
Networking
Controller Type Intel® XL710-BM1
Data Transfer Rate 10GbE
Port Quantity Quad RJ45 connectors with speed up to 10Gb/s per port
Virtualization Features Next-Generation VMDq with up to 256 VMDq VMs supported, SR-IOV with up to 128 virtuals ports, Virtual Machine Load Balancing (VMLB), Advanced Packet Filtering, VLAN support for up to 4,096 VLAN tags, VXLAN and NVGRE support
Power
Comsumtion Operational 15.5W
Environmental Parameters
Operating Temperature Operating temperature: 0°C to 55°C (32°F to 131°F)
Storage temperature: -40°C to 70°C (-40°F to 158°F)
Storage humidity: 90% non-condensing relative humidity at 35°C
Software / System Requirements
OS Supports Windows® Server 2012 R2, 2012, 2008 R2 x86-64
Linux RedHat EL 6.5 and 7.0 IA-32, X86-64, and IA-64
Linux SuSE SLES 11 SP3 and 12 IA-32, X86-64, and IA-64
FreeBSD 9 and 10 IA-32, X86-64, and IA-64
UEFI 2.1 and 2.3 X86-64 and I-64
VMware ESXi 5.1 and ESXi 5.5 X86-64
Miscellaneous
Features Intel® Flow Director
Multiple queues: 1,536 Tx and Rx queues per port
Tx/Rx IP, SCTP, TCP, and UDP checksum offloading (IPv4, IPv6) capabilities
MSI-X support to minimize interrupt overhead and to allow load-balancing be-tween multiple cores/CPUs
ROHS RoHS compliant 6/6
Device Type Ethernet Controller
Dimensions (WxDxH) Card PCB dimensions: 5.9in (14.99cm) x 2.73in (6.90cm) (L x H)
Height of end brackets: standard - 4.725in (12cm), low-profile - 3.13in (7.94cm)
Form Factor Low-Profile Standard Short-length Form Factor
Interface (Bus) Type PCI Express 3.0 (8GT/s)
Networking
Controller Type Intel® XL710-BM1
Data Transfer Rate 10GbE
Port Quantity Quad RJ45 connectors with speed up to 10Gb/s per port
Virtualization Features Next-Generation VMDq with up to 256 VMDq VMs supported, SR-IOV with up to 128 virtuals ports, Virtual Machine Load Balancing (VMLB), Advanced Packet Filtering, VLAN support for up to 4,096 VLAN tags, VXLAN and NVGRE support
Power
Comsumtion Operational 15.5W
Environmental Parameters
Operating Temperature Operating temperature: 0°C to 55°C (32°F to 131°F)
Storage temperature: -40°C to 70°C (-40°F to 158°F)
Storage humidity: 90% non-condensing relative humidity at 35°C
Software / System Requirements
OS Supports Windows® Server 2012 R2, 2012, 2008 R2 x86-64
Linux RedHat EL 6.5 and 7.0 IA-32, X86-64, and IA-64
Linux SuSE SLES 11 SP3 and 12 IA-32, X86-64, and IA-64
FreeBSD 9 and 10 IA-32, X86-64, and IA-64
UEFI 2.1 and 2.3 X86-64 and I-64
VMware ESXi 5.1 and ESXi 5.5 X86-64
Miscellaneous
Features Intel® Flow Director
Multiple queues: 1,536 Tx and Rx queues per port
Tx/Rx IP, SCTP, TCP, and UDP checksum offloading (IPv4, IPv6) capabilities
MSI-X support to minimize interrupt overhead and to allow load-balancing be-tween multiple cores/CPUs
ROHS RoHS compliant 6/6
Parametry
| Výrobce | Supermicro |
